Dahua KTP04 Pro IP Villa Outdoor Station & Indoor Monitor
- Outdoor Door Station (VTO series):
Full metal casing design for durability.
Customizable number of buttons (ideal for multi-resident villas).
2MP HD CMOS camera (1/2.8") with IR illumination and auto WDR for clear images day/night.
Two-way video call with indoor monitors.
Supports two locks for access control.
Unlock options: IC card, indoor monitor, or mobile app.
IK08 impact resistance and IP65 weatherproof rating (requires silicone sealant for proper installation).
PoE power supply for simplified cabling.
Optional rain cover and customizable front covers (red-brown or dark blue).
H.264/H.265 video compression for efficient bandwidth use.
- Indoor Monitor (VTH series):
Elegant aluminum alloy design with built-in Linux OS.
7-inch capacitive touchscreen (1024 Ă— 600 resolution).
Displays live video when receiving a call from the door station.
6-channel wired alarm zone + 1 alarm output for enhanced security.
Wi-Fi and PoE support for flexible installation.
High-performance speaker and microphone for clear voice calls.
Customizable Do Not Disturb mode.
H.265/H.264 video decoding for smooth playback.
Can send messages to a management center.
Use the Dahua app for remote communication and unlocking when away from home.
Customize the number of outdoor station buttons to match villa residents.
Integrate with alarms and IP cameras for a unified smart home security system.
PoE simplifies installation—one cable for both power and data.
Optional rain cover and front panel colors allow aesthetic customization.
Weatherproofing: Proper sealing with silicone is required to maintain IP65 protection.
Power Supply: Ensure your PoE switch complies with 802.3af/at standards; otherwise, the system may not power correctly.
Installation: Incorrect mounting or sealing can compromise durability and water resistance.
Compatibility: Always check firmware updates and app compatibility for smooth operation.
- 1 Ă— IP Villa Door Station (full metal casing, customizable buttons)
- 1 Ă— IP Indoor Monitor (7-inch VTH series)
- Mounting accessories (brackets, screws).
- Quick Start Guide and manuals.
- Rain cover (included).
- PoE-ready design (PoE switch not always included).
